Novastar MCTRL300 LED Display Controller 2 Ethernet Ports

Novastar MCTRL300 is a compact and high-performance independent LED display controller from NovaStar’s M3 Series, ideal for small-to-medium LED screen projects. It supports a maximum input resolution of 1920×1200@60Hz and a pixel loading capacity of up to 1.3 million pixels, delivering clear and stable video output. Equipped with 1×SL-DVI video input, 1×audio input, and 2×Gigabit Ethernet outputs, it enables reliable signal transmission with cable redundancy support. The controller supports data transmission distances up to 100 meters via Ethernet, ensuring stable short-to-medium range connectivity. It features pixel-level brightness and chroma calibration for uniform image quality and a light sensor port for automatic brightness adjustment. With a USB Type-B port for PC communication and a UART port for cascading up to 20 units, it supports scalable control for large displays. Certified CE, RoHS, FCC, it meets global safety standards. Widely used in rental events, retail displays, shopping malls, security monitoring centers, and fixed installations, the MCTRL300 is a cost-effective solution for diverse LED display applications.
